C9200L-48P-4X-A
Denumirea produsului: Cisco Catalyst 9200L - Network Advantage - switch - L3 - Managed - 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ (uplink) - rack-mountable - PoE+ (1440 W)
EAN:
0889728170314
Part number: C9200L-48P-4X-A
Pentru a stabili detaliile vă rugăm să ne contactaţi prin telefon sau prin e-mail.
Alegeți un produs necesar
Livrare estimata:
Descriere
Citeşte mai multe despre Cisco Catalyst 9200L - Network Advantage - switch - L3 - Managed - 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ (uplink) - rack-mountable - PoE+ (1440 W)
Specificaţie
| Caracteristicile managementului | |
| De tip Switch | Gestionate |
| Strat Switch | L3 |
| Acceptate Quality of Service (QoS) | Da |
| Gestionare pe baza de Web | Da |
| acceptate MIB | BRIDGE-MIB, CISCO-BRIDGE-EXT-MIB, CISCO-BULK-FILE-MIB, CISCO-CABLE-DIAG-MIB, CISCO-CALLHOME-MIB, CISCO-CEF-MIB, CISCO-CIRCUIT-INTERFACE-MIB, CISCO-CONFIG-COPY-MIB, CISCO-CONFIG-MAN-MIB, CISCO-DEVICE-LOCATION-MIB, CISCO-DHCP-SNOOPING-MIB, CISCO-EIGRP-MIB, CISCO-EMBEDDED-EVENT-MGR-MIB, CISCO-ENTITY-FRU-CONTROL-MIB, CISCO-ENTITY-SENSOR-MIB, CISCO-ENTITY-VENDORTYPE-OID-MIB, CISCO-ERR-DISABLE-MIB, CISCO-FLASH-MIB, CISCO-FLOW-MONITOR-MIB, CISCO-FTP-CLIENT-MIB, CISCO-HSRP-EXT-MIB, CISCO-HSRP-MIB, CISCO-IETF-BFD-MIB, CISCO-IETF-PPVPN-MPLS-VPN-MIB, CISCO-IETF-PW-MPLS-MIB, CISCO-IF-EXTENSION-MIB, CISCO-IGMP-FILTER-MIB, CISCO-IMAGE-LICENSE-MGMT-MIB, CISCO-IMAGE-MIB, CISCO-IP-CBR-METRICS-MIB, CISCO-IP-STAT-MIB, CISCO-IP-TAP-MIB, CISCO-IP-URPF-MIB, CISCO-IPSEC-FLOW-MONITOR-MIB, CISCO-IPSEC-MIB, CISCO-IPSEC-PROVISIONING-MIB, CISCO-IPSLA-AUTOMEASURE-MIB, CISCO-IPSLA-ECHO-MIB, CISCO-IPSLA-JITTER-MIB, CISCO-L2-CONTROL-MIB, CISCO-L2L3-INTERFACE-CONFIG-MIB, CISCO-LAG-MIB, CISCO-LICENSE-MGMT-MIB, CISCO-LOCAL-AUTH-USER-MIB, CISCO-MAC-NOTIFICATION-MIB, CISCO-MDI-METRICS-MIB, CISCO-MEDIA-METRICS-MIB, CISCO-MEMORY-POOL-MIB, CISCO-MPLS-LSR-EXT-STD-MIB, CISCO-NBAR-PROTOCOL-DISCOVERY-MIB, CISCO-NHRP-EXT-MIB, CISCO-NTP-MIB, CISCO-PAGP-MIB, CISCO-PORT-SECURITY-MIB, CISCO-PORT-STORM-CONTROL-MIB, CISCO-POWER-ETHERNET-EXT-MIB, CISCO-PRIVATE-VLAN-MIB, CISCO-PROCESS-MIB, CISCO-PRODUCTS-MIB, CISCO-RF-MIB, CISCO-RTP-METRICS-MIB ,CISCO-RTTMON-ICMP-MIB, CISCO-STACKWISE-MIB, CISCO-STP-EXTENSIONS-MIB, CISCO-SYSLOG-MIB, CISCO-TCP-MIB, CISCO-UDLDP-MIB, CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB, ENTITY-MIB, HC-ALARM-MIB, HC-RMON-MIB, IEEE8023-LAG-MIB, IF-MIB, IP-FORWARD-MIB, IP-MIB, LLDP-EXT-MED-MIB, LLDP-MIB, MAU-MIB, MPLS-L3VPN-STD-MIB, MPLS-LSR-STD-MIB, MPLS-VPN-MIB, OLD-CISCO-CHASSIS-MIB, OLD-CISCO-CPU-MIB, OLD-CISCO-INTERFACES-MIB, OLD-CISCO-IP-MIB, OLD-CISCO-MEMORY-MIB, OLD-CISCO-SYS-MIB, OLD-CISCO-TCP-MIB, OLD-CISCO-TS-MIB, POWER-ETHERNET-MIB, RFC1213-MIB, RMON-MIB, RMON2-MIB, SMON-MIB, SNMPv2-MIB, SONET-MIB, TCP-MIB, UDP-MIB |
| Conexiune | |
| Număr de porturi Ethernet Basic switching RJ-45 | 48 |
| Tip de porturi Ethernet Basic switching RJ-45 | Gigabit Ethernet (10/100/1000) |
| Cantitate module SFP instalate | 2 |
| Cantitate module SFP+ instalate | 2 |
Cantitate porturi USB 2.0
|
3 |
| Reţea | |
| Reţea standard | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Suport 10G | Da |
| Tehnologie de cablare fibră cupru | 100BASE-FX,1000BASE-LX,1000BASE-SX,1000BASE-T |
| Rutarea IP | Da |
| Intrări routing | 3000 |
| Spanning protocol de copac | Da |
| Tehnologii virtualizare rețea | Virtual Extensible LAN (VXLAN) |
| Căi IPv4 | 3000 |
| Căi IPv6 | 1500 |
| Numărul de VLANs | 1024 |
| Transmisie de date | |
|
Capacitatea de comutare
|
176 Gbit/s |
| Rată de expediere (forwarding) | 130,95 Mpps |
|
Mărimea tabelei de adresare
|
16000 intrari |
| Jumbo suportã frame-uri | Da |
| Cadre Jumbo | 9198 |
| Memorie buffer packete | 6 Mega bites |
| Securitate | |
| Listă de Control Acces (ACL) | Da |
| Algoritmul de securitate suportat | 128-bit AES |
| Specificații (mod transmitere) multicast | |
| Suportul pentru multicast | Da |
| Protocoale | |
| Protocoale întreţinere | SNMPv1/v2c/v3 |
| Routing de protocol | CDP,EIGRP,OSPF,RIP,VRRP |
| Design | |
| Care pot fi stivuite | Da |
| Culoarea produsului | Gri |
|
Siguranţă
|
IEC 60950-1, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950.1, Class I Equipment |
|
Compatibilitate electromagnetică
|
47 CFR Part 15, CISPR 22 Class A, CISPR 32 Class A, CNS 13438, EN 300 386, EN 55022 Class A, EN 55032 Class A, EN61000-3-2, EN61000-3-3, ICES-003 Class A, KN 32, TCVN 7189 Class A, V-3 Class A, CISPR 24, EN 300 386, EN 55024, KN 35, TCVN 7317 |
| Certificare | RoHS |
| Performanță | |
|
Tipul de memorie
|
DRAM |
|
Memorie internă
|
2048 Mega bites |
| Memorie volatilă | 4096 Mega bites |
|
Priza si Pornire
|
Da |
| Nivel zgomot | 42 dB |
|
Întretimp între eşecuri
|
346270 h |
| Managementul energiei | |
| Sursă de curent inclusă | Da |
| Redundant sursa de alimentare (RPS) sprijin | Da |
| Tensiune AC intrare | 100 - 240 V |
| Frecvență de intrare AC | 50 - 60 Hz |
| Curent de intrare | 6 - 12 A |
| Curent pe cablu net (PoE) | |
| Power over Ethernet (PoE) Suport | Da |
| Număr de porturi curent pe cablu net (PoE+) | 48 |
| Putere electrică prin Ethernet (PoE) energie per port | 30 W |
| Buget total curent pe cablu net (PoE) | 740 W |
| Conditii de mediu | |
| Interval de temperatură de funcţionare (T-T) | -5 - 45 °C |
| Intervalul de temperatură pentru depozitare | -40 - 70 °C |
| Interval relativ operaţional de umiditate | 5 - 90% |
| Altitudinea de operare | 0 - 3000 m |
|
Disiparea căldurii
|
3412 BTU/h |
| Greutate şi dimensiuni | |
| Lărgime | 445 milimetri |
| Adâncime | 329 milimetri |
|
Înălţime
|
44 milimetri |
|
Greutate
|
4,8 kilograme |
